Isomat Spar Cleats



Cleats commonly used on Spars produced by Isomat, Sparcraft and Charleston Spars.
These Builders also commonly used Kenyon Spar Cleats, See Spar Cleats Main Page.


Four Hole Spar Cleat - 4 3/4" / 120mm Long: NGC-5:
Cast, Black anodized Aluminum Cleat is 120mm (4 3/4") long, and fastens with (4) 5mm (3/16") fasteners on 40mm (1 9/16") x 35mm (1 3/8") hole centers. Installed in the factory with rivets, can also be installed with machine screws.



NGC-5

Four Hole Spar Cleat - 6 3/8" / 160mm Long: NGC-6:
Cast, Black anodized Aluminum Cleat is 160mm (6 3/8") long, and fastens with (4) 5mm (3/16") fasteners on 50mm (2") x 40mm (1 9/16") hole centers. Installed in the factory with rivets, can also be installed with machine screws.



NGC-6

Four Hole Spar Cleat - 7 7/8" / 200mm Long: NGC-8:
Cast, Black anodized Aluminum Cleat is 200mm (7 7/8") long, and fastens with (4) 5mm (3/16") fasteners on 50mm (2") x 40mm (1 9/16") hole centers. Installed in the factory with rivets, can also be installed with machine screws.


NGC-8






Two (2) Hole Spar Cleat - 4 3/4" / 120mm Long: NGC-5-2A:
Clear anodized Cast Aluminum Spar Cleat is 120mm (4 3/4") long, and fastens with (2) 5mm (3/16") RH screws on 35mm (1 3/8") hole centers. Rectangular Base is 60mm (2 3/8") long x 26mm (1") wide.



Two (2) Hole Spar Cleat - 6 3/8" / 160mm Long: NGC-6-2A:
Clear anodized Cast Aluminum Spar Cleat is 160mm (6 3/8") long, and fastens with (2) 5mm (3/16") RH screws on 35mm (1 3/8") hole centers. Rectangular Base is 70mm (2 3/4") long x 30mm (1 1/8") wide.



Two (2) Hole Spar Cleat - 7 7/8" / 200mm Long: NGC-8-2A:
Clear anodized Cast Aluminum Spar Cleat is 200mm (7 7/8") long, and fastens with (2) 8mm (5/16") RH screws on 50mm (2") hole centers.
