Mainsheet Tangs Flat Strap Tangs mount on a single bolt through the Outhaul casting, for use in end boom sheeting applications. Mainsheet Tangs swivel to align with sheet loads and are required on all roller reefing booms. Commonly used in pairs to allow for attachment of topping lift or boom hanger. See also, Tangs Main Page. |
|
|
|
|
|
3 1/2" Mainsheet Tang for 3/8" Bolt: K-359:
Flat Mainsheet Tang attaches to Boom end casting using a 3/8" bolt. For use with Spartan CD-1, Kenyon B-Section, and similar sized booms. Mainsheet Tang is 3 1/2" long x 1" wide x .076" thick with (1) 3/8" mounting hole and (1) 5/8" hole for attachment of Mainsheet block. Hole centers are 2 1/2" apart. SP-260, Sch 85-70
|
|
|
4" Mainsheet Tang for 3/8" Bolt: Sch 85-68X: Flat Mainsheet Tang attaches to Boom end casting using a 3/8" bolt. For use with Spartan CD-2, Kenyon D-Section, and similar sized booms. Mainsheet Tang is 4" long x 1" wide x .090" thick with (1) 3/8" mounting hole and a 1/2" x 3/4" slot for attachment of Mainsheet block. Hole centers are 3" apart. dtc
|
|
|
5" Mainsheet Tang for 3/8" Bolt: K-360:
Flat Mainsheet Tang attaches to Boom end casting using a 3/8" bolt. For use with Spartan CD-2, Kenyon D-Section, and similar sized booms. Mainsheet Tang is 5" long x 1" wide x .076" thick with (1) 3/8" mounting hole and a 1/2" x 1" slot for attachment of Mainsheet block. SP-261
|
|
|
6" Mainsheet Tang for 3/8" Bolt: K-361H:
Heavy Duty Flat Mainsheet Tang attaches to Boom end casting using a 3/8" bolt. For use with Kenyon E-Section and larger booms. Mainsheet Tang is 6" long x 1" wide x 3/16" (.188") thick with (1) 3/8" mounting hole and a 1/2" x 1" slot for attachment of Mainsheet block. K-85-X1X
|
|
| Long Angled Mainsheet Tang for 3/8" Bolt: RR 85-68XL:
Long Mainsheet Tang attaches to Boom end casting using a 3/8" bolt. For use with Rig-Rite #6, Kenyon E-Section, and similar sized booms. Mainsheet Tang is 9 1/4" long x 1" wide x 1/8" (.120") thick with (1) 3/8" centered mounting hole and (2) 3/8" x 1" slots. Lower slot is for attachment of Mainsheet block, upper slot for attachment of topping lift. Upper end is angled 25 degrees forward to better align with topping lift.
|
|
|
|
|
|
5" Mainsheet Tang for 1/2" Bolt: K-360-8:
Flat Mainsheet Tang attaches to Boom end casting using a 1/2" bolt. For use with Spartan CD-2, Kenyon D-Section, and similar sized booms. Mainsheet Tang is 5" long x 1" wide x .076" thick with (1) 1/2" mounting hole and a 1/2" x 1" slot for attachment of Mainsheet block. K-85-X2
|
|
|
5 3/4" Mainsheet Tang for 1/2" Bolt, Wide: K-361W-8:
Wide Flat Mainsheet Tang attaches to Boom end casting using a 1/2" bolt. For use with Spartan CD-2, Kenyon D-Section, and similar sized booms. Mainsheet Tang is 5 3/4" long x 1 1/4" wide x 1/8" (.120") thick with (1) 1/2" mounting hole and a 1/2" x 1" slot for attachment of Mainsheet block. K-85-X2W
|
|
|
6" Mainsheet Tang for 1/2" Bolt: K-361H-8:
Heavy Duty Flat Mainsheet Tang attaches to Boom end casting using a 1/2" bolt. For use with Kenyon E-Section and larger booms. Mainsheet Tang is 6" long x 1" wide x 3/16" (.188") thick with (1) 1/2" mounting hole and a 1/2" x 1" slot for attachment of Mainsheet block. K-85-X3 |
|
