| Spinnaker Cars for 1 1/4" T-Track |
|
|
|
These Spinnaker Cars are designed to fit on US Standard 1 1/4" T-track, or SS Flat Track,
(1 1/4" x 3/16") unless otherwise noted, and are held in place on the
track either by a spring or screw pin, or by means of a line control system. Racing boats,
large boats and those stowing their poles on the mast will generally use a line control
system, for its ease and handling convenience.
Note that Spinnaker Cars for Metric T-Track will also fit the (thinner flanged) US standard
T-Track, but the reverse is Not the case, See:
Spinnaker Cars for Metric T-Track. Spinnaker Cars are of three primary varieties: Ring Cars for standard Piston pole ends, Toggle Cars for standard Piston pole ends in heavy duty or mast storage applications, and specific Cars to fit the variety of special inboard Spinnaker Pole Ends available. Please note that Ring Cars are not designed for, or recommended for vertical pole stowage applications. See also, Spinnaker Cars for T-Track, Spinnaker Poles & Parts, and Track. |
||
|
|
||
|
Spinnaker Cars for 1 1/4" T-Track
|
||
|
|
||
| Standard Spinnaker Cars (w/ Pin Stop) for 1 1/4" T-Track | ||
|
Spinnaker Car w/ Spring Pin for 1 1/4" T-Track: K-300-10:
Welded SS Spinnaker Car with Ring to fit 1 1/4" T-Track. Formed SS Slide with SS Screw Pin is welded to 5/16" x 1 7/16" ID Ring. Slide is 3 3/8" long x 1 1/2" wide, and projects 2" (maximum) from Track surface. |
 |
|
| Spinnaker Car w/ Screw Pin for 1 1/4" T-Track: K-300-10T: | ||
| Welded SS Spinnaker Car with Ring to fit 1 1/4" T-Track. Formed SS Slide with SS Thumb Screw Pin is welded to 5/16" x 1 7/16" ID Ring. Slide is 3 3/8" long x 1 1/2" wide, and projects 2" (maximum) from Track surface. |
 |
|
|
Cast Spinnaker Car for 1 1/4" T-Track: NF 10681:
Chrome plated Cast Bronze Spinnaker Car to fit 1 1/4" T-Track. Cast Slide has 7/16" x 1 3/8" ID Ring and SS Spring stop Pin. Slide is 3 1/2" long x 1 11/16" wide, and projects 2 1/8" (maximum) from Track surface. |
 |
|
|
Spinnaker Car for 1 1/4" T-Track: PP 73-33W:
SS Spinnaker Car to fit 1 1/4" T-Track. Cast SS Slide has welded 7/16" x 2" ID Ring and SS Spring stop Pin which can be locked in the retracted position. Slide is 3 1/2" long x 1 11/16" wide, and projects 3" (maximum) from Track surface. |
 |
|
|
Cast Spinnaker Car for 1 1/4" T-Track: Mer 450S:
Heavy-duty Cast SS Spinnaker Car to fit 1 1/4" T-Track. Heavy-duty Car is investment Cast in one piece and has SS Spring stop Pin. Integral Ring is (minimum) 7/16" x 1 7/8" ID. Slide is 3 1/2" long x 1 3/4" wide, and projects 2 1/2" (maximum) from Track surface.
|
 |
|
|
Cast Spinnaker Car for 1 1/4" T-Track: Sch 73-33:
Heavy-duty Cast SS Spinnaker Car with Ring to fit 1 1/4" T-Track. Heavy-duty Car is investment Cast in one piece and has SS Spring stop Pin. Integral Ring is (minimum) 7/16" x 2" ID. Slide is 4 1/4" long x 1 5/8" wide, and projects 2 3/4" (maximum) from Track surface.
|
 |
|
|
Spinnaker Car w/ Liners & Spring Pin: Sch 17-87:
Welded SS Spinnaker Car with Ring and plastic liners to fit 1 1/4" T-Track. Formed SS Slide with SS Spring Pin is welded to 7/16" x 2" ID Ring. Slide is 4" long x 1 11/16" wide, and projects 2 7/8" (maximum) from Track surface. Replacement Liners are: Sch 172LP-T4:
|
 |
|
| Liners for Sch 17-87 Spinnaker Car: Sch 172LP-T4: | ||
|
Replacement Liners for Sch 17-87 Spinnaker Cars. Black plastic liners are 3 15/16"
long with bottom protrusions and side tabs to hold them in place when Car is removed from track.
Sold in pairs only.
|
 |
|
|
Spinnaker Car w/ Liners for 1 1/4" T-Track: RF 701X:
Welded SS Spinnaker Car with plastic liners to fit 1 1/4" T-Track. Formed SS Slide with SS Spring stop Pin is welded to 7/16" x 1 3/4" ID Ring. Slide is 4" long x 1 5/8" wide, and projects 2 7/8" (maximum) from Track surface. Earlier versions of this Car had perforated sides to hold liners in place, newer versions use liners that fit over the Car ends. New-style plastic liners will fit both versions, Replacement Liners are: RF 723-4LP:
|
 |
|
| Liners for RF 701 Spinnaker Car (pair): RF 723-4LP: | ||
|
Replacement Liners for RF 701 and RF 703 Spinnaker Cars.
Black plastic liners are 4 1/4" long to fit 4" long Car, and are sold in pairs only. |
||
|
|
||
| Towable Spinnaker Cars for 1 1/4" T-Track | ||
| Towable Spinnaker Car w/ Liners for 1 1/4" T-Track: RF 703X: | ||
|
Welded SS Spinnaker Car with plastic liners to fit 1 1/4" T-Track. Formed SS Slide with towing bails
is welded to 7/16" x 1 3/4" ID Ring. Slide is (maximum) 6 1/4" long x 1 5/8" wide, and projects 2 7/8"
(maximum) from Track surface. Note: Car can only be positioned with control lines.
This item is no longer available.
Earlier versions of this Car had perforated sides to hold liners in place, newer versions used liners
that fit over the Car ends. New-style plastic liners will fit both versions. Replacement Liners are: RF 723-4LP:
|
||
|
Liners for RF 703 Spinnaker Car: RF 723-4LP:
Replacement Liners for RF 701 and RF 703 Spinnaker Cars. Black plastic liners are 4 1/4" long to fit 4" long Car, and are sold in pairs only. |
||
| Towable Spinnaker Car w/ Liners for 1 1/4" T-Track: Sch 17-84: | ||
|
Welded SS Spinnaker Car with towing bails and plastic liners to fit 1 1/4" T-Track.
Formed SS Slide is welded to 7/16" x 2" ID Ring. Slide is 5" long (6 5/8" w/ bails) x 1 11/16" wide,
and projects 3" (maximum) from Track surface. Note: Car can only be positioned with control lines.
Replacement Liners are: Sch 172LP-T5:
|
 |
|
| Liners for Sch 17-84 Spinnaker Car: Sch 172LP-T5: | ||
|
Replacement Liners for Sch 17-84 Spinnaker Cars. Black
plastic liners are 4 15/16" long with bottom protrusions and side tabs to hold them in
place when Car is removed from track. Sold in pairs only.
|
 |
|
| Towable Spinnaker Car w/ Rollers for 1 1/4" T-Track: NF 10688: | ||
|
Heavy-duty Cast Spinnaker Car with rollers to fit 1 1/4" T-Track.
Chrome plated Cast Bronze Car has 7/16" x 1 3/4" ID Ring with towing
shackles, and features SS rollers against the top and sides of the track to
insure free rolling under both side and compressive loads. Slide is 4 7/8"
long (without shackles) x 2 5/16" wide, and projects 3" (maximum) from Track
surface. Note: Car can only be positioned with control lines.
|
 |
|
|
|
||
| Towable Spinnaker Cars w/ Pin Stop for 1 1/4" T-Track | ||
|
Towable Spinnaker Car w/ Pin Stop: Mer 4503-230:
Heavy-duty Cast SS Spinnaker Car to fit 1 1/4" T-Track. Investment Cast SS Slide has a SS Spring Pin which can be locked in the retracted position, and (2) shackles for towing applications. Ring is 7/16" x 1 7/8" ID, Slide is 4 1/4" long (without shackles) x 1 3/4" wide, and projects 2 1/2" (maximum) from Track surface.
|
 |
|
|
Towable Spinnaker Car w/ Screw Pin Stop: Sch 73-31X: SS Spinnaker Car to fit 1 1/4" T-Track. Formed SS Slide has welded bails for towing applications and SS Screw Pin to lock it in position. Slide has Large 7/16" x 2" ID Ring and is 5 1/2" long (6 1/2" w/ bails) x 1 9/16" wide, projecting 2 3/4" (maximum) from Track surface. This item is no longer available. Replacement Screw Pin, Sch 172SP is available, below.
|
 |
|
| Replacement Screw Pin for Sch 1 1/4" Cars: Sch 172SP: | ||
|
Replacement Thumb Screw Pin for Sch 73-31X and other Schaefer Cars and Slides for 1
1/4" T-Track. SS Screw Pin has 7/8" knurled head with a 7/16-20 thread and a 3/8" tip. Screw is 9/16"
long beneath the Head.
|
||
|
Towable Spinnaker Car w/ Pin Stop & Liners: Sch 17-75X: SS Spinnaker Car with plastic liners to fit 1 1/4" T-Track. Formed SS Slide has welded bails for towing applications and a lock-up Spring Pin stop when movement is not desired. Slide has Large 7/16" x 2" ID Ring and is 5" long (6" w/ bails) x 1 5/8" wide, projecting 2 3/4" (maximum) from Track surface. This item is no longer available. Replacement Liners are: Sch 172LP-5X:
|
||
| Liners for Sch 17-75X Traveller Slide: Sch 172LP-5X: | ||
|
Replacement Liners for Sch 17-75X Spinnaker Car (and other 5" slides) for 1 1/4"
T-Track. Black plastic liners are (maximum) 5 1/4" long. Sold in pairs only.
|
 |
|
| Towable Spinnaker Car w/ Pin Stop & Liners: For RC-125S: | ||
|
SS Spinnaker Car with plastic liners to fit 1 1/4" T-Track. Investment Cast 17-4 SS Slide has a
SS Screw stop Pin to lock it in place, and holes to add (2) 1/4" shackles for towing applications.
Ring is 3/8" x 1 5/8" ID, Slide is (maximum) 5" long x 1 3/4" wide, and projects 2 1/4" (maximum)
from Track surface. Replacement Liners, below, are also available.
|
 |
|
| Liners for RC-125 Spinnaker Car: For LP-125-475: | ||
|
Replacement Liners for For RC-125S Spinnaker Car, above. Plastic liners
are 4 3/4" long and are sold in pairs only. SCL-5-331013
|
||
|
|
||
| Toggle Cars for 1 1/4" T-Track | ||
| Spinnaker Car w/ FC Toggle for 1 1/4" T-Track: For FC-125: | ||
|
Heavy-duty Spinnaker Car with Pivoting Toggle to fit 1 1/4" T-Track. Extruded Aluminum Slide has
towing shackles and plastic liners to minimize friction. Toggle allows both vertical and horizontal
movement while eliminating twisting motion of the Spinnaker Pole. SS Toggle is 2" ID and features
a delrin bushing on the cross pin to cushion the pole end and reduce noise. Slide is 4 1/2" long
(without shackles) x 1 3/4" wide, unit projects 5" (maximum) from Track surface.
This item is no longer available.
Replacement Liners are: For LP-125-45B:
|
|
|
| Liners w/ Button for FC-125 Spinnaker Car: For LP-125-45B: | ||
|
Replacement Liners with molded Button for For FC-125 Spinnaker Car, as pictured above.
Plastic liners are 4 1/2" long and are sold in pairs only. Note that these cars have been
produced for use with 2 different Liner configurations. If your Car does not have a central hole to
engage the integral molded Button, then order For LP-125-45.
|
||
| Spinnaker Car w/ FC Toggle & Control Blocks: For FC-125-2: | ||
|
Long Heavy-duty Spinnaker Car with Pivoting Toggle and Control Blocks to fit 1 1/4" T-Track.
Extruded Aluminum Slide incorporates (2) SS blocks for a 2-1 purchase with up to 3/8" line, and
plastic liners to minimize friction. Toggle allows both vertical and horizontal movement while
eliminating twisting motion of the Spinnaker Pole.
SS Toggle is 2" ID and features a delrin bushing on the cross pin to cushion the pole end and reduce
noise. Slide is 8" long x 1 3/4" wide, unit projects 5" (maximum) from Track surface.
|
 |
|
|
|
||
| Cars with Bayonet Pins for 1 1/4" T-Track | ||
| Cars with Forespar TS Pins ----------------------------- | ||
|
Aluminum Spinnaker Car w/ TS Pin: For TS-125A:
Heavy-duty Aluminum Spinnaker Car for 1 1/4" T-Track has Pivoting Toggle with Forespar TS Pin. Extruded Aluminum Slide has plastic liners to minimize friction and provisions for 1/4" towing shackles. Slide is 4 1/2" long (without shackles) x 1 3/4" wide, Toggle projects 4 1/2" (maximum) from Track surface. Replacement Liners, below, are also available. TS Pin (1" OD x 3 5/8" long) fits all Forespar TS type Spinnaker Pole ends. When used with Standard T-Track and TS type Spinnaker Pole end, 5" must be subtracted from Pole length to maintain "J" measurement. AT-125S
|
 |
|
| Liners for TS-125A Spinnaker Car: For LP-125-45: | ||
| Replacement Liners for For TS-125A Aluminum Spinnaker Car,
as pictured above. Plastic liners are 4 1/2" long and are sold in pairs only. Note that these
cars have been produced for use with 2 different Liner configurations. If your Car is different than
that pictured above, and has a central hole to engage a single integral molded Liner Button, then
order For LP-125-45B.
|
||
|
Stainless Steel Spinnaker Car w/ TS Pin: For TS-125S:
Heavy-duty SS Spinnaker Car for 1 1/4" T-Track has Pivoting Toggle with Forespar TS Pin. Cast Stainless Steel Slide has plastic liners to minimize friction and provisions for 1/4" towing shackles. Slide is 5" long (without shackles) x 1 3/4" wide, Toggle projects 4 1/2" (maximum) from Track surface. Replacement Liners, below, are also available. TS Pin (1" OD x 3 5/8" long) fits all Forespar TS type Spinnaker Pole ends. When used with Standard T-Track and TS type Spinnaker Pole end, 5" must be subtracted from Pole length to maintain "J" measurement. T-125S
|
 |
|
| Liners w/ Button for TS-125S Spinnaker Car: For LP-125-5B: | ||
|
Replacement Liners with molded Button for For TS-125S SS Spinnaker Car,
as pictured above. Plastic liners are 5" long and are sold in pairs only. |
||
|
TS Pin & Toggle for Spinnaker Car: For TS-PT:
Replacement TS Pin & Toggle Assembly for all Forespar TS type Spinnaker Cars. Stainless Steel TS Pin is 1" OD x 3 5/8" long, SS Toggle is 1" high with hole for a 1/2" Pin, and is 2 3/4" between Pin centers.
|
|
|
|
Double Spinnaker Car w/ Two (2) TS Pins: RR 73-125DC-TS: Unique, Heavy-duty Double Spinnaker Car for 1 1/4" T-Track has two (2) Forespar TS Pins on Pivoting Toggles. Cast Chrome plated Bronze Slide includes towing shackles for line control, or can be positioned with removable Screw Pin. Ideal arrangement for use with twin downwind poles. Slide is 10" long (without shackles) x 1 3/4" wide, Toggles projects 3 1/4" (maximum) from Track surface. TS Pins (1" OD x 3 5/8" long) fit all Forespar TS type Spinnaker Pole ends. When used with Standard T-Track and TS type Spinnaker Pole ends, 5" must be subtracted from Pole length to maintain "J" measurement. J/FST SC
|
||
|
|
||
| Cars with Sparcraft Pins ------------------------------- | ||
|
Aluminum Spinnaker Car w/ Sparcraft Pin: SPC 73-125ASP: Heavy-duty Aluminum Spinnaker Car for 1 1/4" T-Track has Pivoting Toggle with Sparcraft Bayonet Pin. Extruded Aluminum Slide has plastic liners to minimize friction and includes 1/4" towing shackles. Slide is 4 1/2" long (without shackles) x 1 3/4" wide, Toggle projects 4 1/2" (maximum) from Track surface. Replacement Liners, below, are also available. Sparcraft Bayonet Pin (7/8" OD x 4" long, beneath head) fits all Sparcraft Bayonet type Spinnaker Pole ends. When used with Standard T-Track and Sparcraft Bayonet type Spinnaker Pole end, 5 1/2" must be subtracted from Pole length to maintain "J" measurement. ###
|
||
| Liners for SPC 73-125A Spinnaker Car: SPC LP-125-45: | ||
| Replacement Liners for SPC 73-125A
Spinnaker Cars, above. Plastic liners are 4 1/2" long and are sold in pairs only.
|
||
| Stainless Steel Spinnaker Car w/ Sparcraft Pin: SPC 73-125S: | ||
|
Heavy-duty SS Spinnaker Car for 1 1/4" T-Track has Pivoting Toggle with Sparcraft Bayonet Pin.
Cast Stainless Steel Slide has plastic liners to minimize friction and includes 1/4" towing shackles.
Slide is 5" long (without shackles) x 1 3/4" wide, Toggle projects 4 1/2" (maximum) from Track surface.
Replacement Liners, below, are also available. Sparcraft Bayonet Pin (7/8" OD x 4" long, beneath head)
fits all Sparcraft Bayonet type Spinnaker Pole ends. When used with Standard T-Track and Sparcraft
Bayonet type Spinnaker Pole end, 5 1/2" must be subtracted from Pole length to maintain "J" measurement.
|
 |
|
| Liners for SC 73-125S Spinnaker Car: SPC LP-125-5: | ||
|
Replacement Liners for SPC 73-125S
Spinnaker Cars, above. Plastic liners are 5" long and are sold in pairs only.
|
||
|
Sparcraft Pin & Toggle - 1/2" Pin: SPC 73-13PT-2:
Replacement Sparcraft Bayonet Pin & Toggle (Type 2) Assembly fits all Sparcraft Bayonet type Spinnaker Pole ends, and Spinnaker Cars with a 1/2" vertical Pin and clearance for a 1" Toggle. Assembly includes Sparcraft Bayonet Pin, SPC 73-13P, and SS Toggle SPC 73-12T2.
|
||
|
Sparcraft Bayonet Pin only: SPC 73-13P:
Replacement Sparcraft Bayonet Pin only, fits all Sparcraft Bayonet type Spinnaker Pole ends. Stainless Steel Sparcraft Bayonet Pin is 7/8" OD x 4" long (beneath head), head is 9/16" thick with hole for 1/2" pin. Unit is (maximum) 5 3/4" long.
|
|
|
|
Sparcraft Type 2 Toggle only: SPC 73-12T2:
Replacement Sparcraft Toggle (Type 2) fits Sparcraft Bayonet Pin and Spinnaker Cars with a 1/2" vertical Pin and clearance for a 1" Toggle. Stainless Steel Toggle is 1" high x 1 1/4" wide with holes for 1/2" Pins, and measures 1 5/8" between Pin centers. Horizontal (1/2") Pin is included.
|
||
| Double Spinnaker Car w/ Two (2) Sparcraft Bayonet Pins: SPC 73-125DC: | ||
|
Unique, Heavy-duty Double
Spinnaker Car for 1 1/4" T-Track has two (2) Sparcraft Bayonet Pins on Pivoting
Toggles. Cast Chrome plated Bronze Slide includes towing shackles for line control, or can
be positioned with removable Screw Pin. Ideal arrangement for use with twin downwind
poles. SS Sparcraft Bayonet Pin is 7/8" OD x 4" long (beneath head) and fits all
Sparcraft Bayonet type Spinnaker Pole ends. Slide is 10" long (without shackles) x 1
3/4" wide, Toggles projects 3 1/4" (maximum) from Track surface. When used with
Standard T-Track and Sparcraft Bayonet type Spinnaker Pole end, 4 1/4" must be
subtracted from Pole length to maintain "J" measurement. SC
|
||
|
Sparcraft Pin & Toggle Ass'y - 5/8" Pin: SPC 73-13PT-1: Replacement Sparcraft Bayonet Pin & Toggle (Type 1) Assembly fits all Sparcraft Bayonet type Spinnaker Pole ends, and Spinnaker Cars with a 5/8" vertical Pin and clearance for a 1 3/16" Toggle. Assembly includes Sparcraft Bayonet Pin, SPC 73-13P, and SS Toggle SPC 73-12T1.
|
||
|
Sparcraft Bayonet Pin only: SPC 73-13P:
Replacement Sparcraft Bayonet Pin only, fits all Sparcraft Bayonet type Spinnaker Pole ends. Stainless Steel Sparcraft Bayonet Pin is 7/8" OD x 4" long (beneath head), head is 9/16" thick with hole for 1/2" pin. Unit is (maximum) 5 3/4" long.
|
|
|
|
Sparcraft Type 1 Toggle only: SPC 73-12T1:
Replacement Sparcraft Toggle (Type 1) fits Sparcraft Bayonet Pin and Spinnaker Cars with a 5/8" vertical Pin and clearance for a 1 3/16" Toggle. Stainless Steel Toggle is 1 3/16" high x 1 3/8" wide with holes for 5/8" (Vertical) and 1/2" (Horizontal) Pins, and measures 1 5/8" between Pin centers. Horizontal (1/2") Pin is included.
|
|
|
|
|
||
| Cars with Nicro-Fico Pins ------------------------------ | ||
| Aluminum Spinnaker Car w/ Nicro-Fico 1/2" Pin: NF 73-125AP1: | ||
|
Heavy-duty Aluminum Spinnaker Car for 1 1/4" T-Track has Pivoting Toggle with
Nicro-Fico 1/2" Bayonet Pin. Extruded Aluminum Slide has plastic liners to minimize
friction and includes towing shackles. Slide is 4 1/2" long (without shackles) x 1
3/4" wide, Toggle projects 3" (maximum) from Track surface. Replacement Liners, below,
are also available. Nicro-Fico 1/2" Bayonet Pin (1/2" OD x 3 1/8" long, beneath head)
fits all Nicro-Fico 1/2" Bayonet type Spinnaker Pole ends. When used with Standard T-Track
and Nicro-Fico 1/2" Spinnaker Pole end, 3 3/4" must be subtracted from Pole length to
maintain "J" measurement. ###
|
||
|
Nicro-Fico 1/2" Bayonet Pin only: NF 73-P1:
Replacement Nicro-Fico 1/2" Bayonet Pin only, fits all Nicro-Fico 1/2" Bayonet type Spinnaker Pole ends. Stainless Steel Nicro-Fico 1/2" Bayonet Pin is 1/2" OD x 3 1/8" long (beneath head), head is 3/8" thick with hole for 3/8" pin. Unit is (maximum) 4 3/8" long.
|
|
|
|
Nicro-Fico 1/2" Bayonet Pin Toggle only: NF 73-T1:
Replacement Nicro-Fico 1/2" Bayonet Pin only, fits all Nicro-Fico 1/2" Bayonet type Spinnaker Pole ends. Stainless Steel Nicro-Fico 1/2" Bayonet Pin is 1/2" OD x 3 1/8" long (beneath head), head is 3/8" thick with hole for 3/8" pin. Unit is (maximum) 4 3/8" long.
|
 |
|
| Aluminum Spinnaker Car w/ Nicro-Fico 5/8" Pin: NF 73-125AP2: | ||
|
Heavy-duty Aluminum Spinnaker Car for 1 1/4" T-Track has Pivoting Toggle with Nicro-Fico 5/8"
Bayonet Pin. Extruded Aluminum Slide has plastic liners to minimize friction and includes towing shackles.
Slide is 4 1/2" long (without shackles) x 1 3/4" wide, Toggle projects 3" (maximum) from Track surface.
Replacement Liners, below, are also available. Nicro-Fico 5/8" Bayonet Pin (5/8" OD x 3 1/8" long,
beneath head) fits all Nicro-Fico 5/8" Bayonet type Spinnaker Pole ends. When used with Standard
T-Track and Nicro-Fico 5/8" Spinnaker Pole end, 4" must be subtracted from Pole length to maintain
"J" measurement. ###
|
||
|
Nicro-Fico 5/8" Bayonet Pin only: NF 73-P2:
Replacement Nicro-Fico 5/8" Bayonet Pin only, fits all Nicro-Fico 5/8" Bayonet type Spinnaker Pole ends. Stainless Steel Nicro-Fico 5/8" Bayonet Pin is 5/8" OD x 3 1/8" long (beneath head), head is 7/16" thick with hole for 3/8" pin. Unit is (maximum) 4 5/8" long.
|
 |
|
| Liners for NF 73-125A Spinnaker Cars: NF 73-125LP: | ||
|
Replacement Liners for NF 73-125A
Spinnaker Cars, above. Plastic liners are 4 1/2" long and are sold in pairs only.
|
||
|
|
||
| Cars with Kemp Pins ------------------------------ | ||
|
Spinnaker Car w/ 1 3/16" Bayonet Pin: KM 73-125-BP: Heavy-duty Spinnaker Car fits 1 1/4" T-Track, and incorporates Kemp special 1 3/16" (30.1mm) Bayonet Pin with Toggle. Cast Aluminum slide has plastic liners to minimize friction and eyes for attachment of towing shackles. Slide is (maximum) 6 5/8" (168mm) long x 2" (52mm) wide, replacement Liners, are also available. Kemp special 1 3/16" (30.1mm) OD Bayonet Pin is (maximum) 6 1/8" (155mm) long.
|
 |
|
|
|
||
|
Bell Cars for 1 1/4" T-Track Please Note that Spinnaker Cars with Bells for Metric Pole Ends are commonly used on US standard 1 1/4" T-Track, See: Spinnaker Cars for Metric T-Track. |
||
| Cars with Nicro-Fico/Amco Bells ------------------- | ||
|
Spinnaker Car w/ Nicro-Fico/Amco Bell Fitting: NF 73-125BC: Heavy-duty Aluminum Spinnaker Car for 1 1/4" T-Track incorporates a standard Nicro-Fico/Amco Bell-type fitting with Toggle. Extruded Aluminum Slide has plastic liners to minimize friction and includes towing shackles. Car includes standard Nicro-Fico/Amco Bell-type fitting, which are interchangeable. NF Bell fitting is 1 7/8" (47mm) ID x 2 3/8" (60mm) OD, with a release lanyard on the lower side. Slide is 4 1/2" long x 1 3/4" wide, replacement Liners, below, are also available. Nicro-Fico Bell Pole End Fittings, that the Bell works with, are commonly found on tubes of 3", 3 1/2", and 4" OD, and have a solid, rounded end with a 1 1/2" OD. MMM ### SO J
|
|
|
| Liners for NF 73-125BC Spinnaker Car: NF LP-125-45: | ||
| Replacement Liners for NF 73-125BC Aluminum Spinnaker Car, above. Plastic liners are 4 1/2" long and are sold in pairs only. | ||
~ Back to Spinnaker Car Main Page ~
~ Home ~
