| RWO - XT1 (5/8") Traveller Systems |
|
|
| RWO - XT1 Traveller Systems RWO’s XT1 series Travellers are designed around a hardcote anodized X-Track that measures 5/8" across the top. Designed for use on lightweight dinghies up to 6m (18'), the XT1 Track System is commonly found on boats built in the UK and in the US through the 1970's and '80's. |
|
| Traveller Track Traveller Cars & Car Parts Traveller Ends & Stops Traveller Control Ends & Track Mounting Brackets
|
|
|
|
||
| RWO XT1 Traveller Track | ||
|
RWO XT1 (5/8") X-Track: RWO XT1T-__ft.: RWO's XT1 Traveller Track is a hardcote anodized Aluminum X-Track that measures 5/8" (16mm) across the top, 5/8" across the base and is 3/4" (19mm) high. Track is drilled for #10 (3/16") FH screws on 4" (102mm) centers, screw holes are deep enough to accommodate Adjustable Track Stops (RWO XT1-21). RWO XT1 Traveller Track is available in 2', 3', 4', and 5-foot lengths, and lengths up to 12 feet.
|
|
|
|
|
||
| RWO XT1 Traveller Cars & Car Parts | ||
|
Standard 4-wheel Traveller Car: RWO XT1-40:
Standard Traveller Car for RWO XT1 Traveller Track is formed from SS plate with SS axles and a pivoting bail with removable 3/16" Pin for attachment to mainsheet block. Car rides on 5/8" diameter white Delrin wheels and has 3/16" holes on each end (on 1 7/8" centers) for attachment of optional Beckets or Car Control Adapter with Cam Cleats (below). Car is 2 3/8" long with a maximum width of 1 7/8", and has an ultimate tensile strength of 500 lbs..
|
 |
|
|
|
Becket for RWO XT1-40 Car: RWO XT1-40B:
SS Becket shackle attaches to RWO XT1-40 Traveller Car to provide for a 1-1 Control purchase (2 required).
|
|
|
Aluminum 4-wheel Traveller Car: RWO XT1-40A:
Simple Aluminum Traveller Car for RWO XT1 & similar Traveller Tracks has a pivoting SS bail for attachment to mainsheet block. Black Extruded Aluminum Car rides on 5/8" diameter white Delrin wheels and is 2 9/16" (65mm) long with a maximum width of 2 3/8" (60mm).
|
||
|
4-wheel Traveller Car w/ Control Sheaves: RWO XT1-42:
Traveller Car with Control Sheaves for RWO XT1 Traveller Track is formed from SS plate with SS axles and a pivoting bail with removable 3/16" Pin for attachment to mainsheet block. Car rides on 5/8" diameter white Delrin wheels and has (2) 7/8" Sheaves for 1/4" Control lines. Provides a 2-1 control purchase, or a 3-1 purchase with the addition of (2) RWO XT1-42B Beckets. Car is 2 3/4" long with a maximum width of 1 7/8", and has an ultimate tensile strength of 500 lbs..
|
|
|
|
|
Replacement Sheave - XT1 Traveller: RWO XT1-42S: Replacement Sheave for XT1-42 Traveller Car and XT1 Control Ends. Black plastic Sheave is 21mm (7/8") OD x 9mm (<3/8") wide x 7mm (<5/16") ID.
|
|
|
|
Becket for RWO XT1-42 Car: RWO XT1-42B:
SS Becket shackle attaches to RWO XT1-42 Traveller Car to increase from a 2-1 to a 3-1 Control line purchase (2 required).
|
|
| 4-wheel Traveller Car w/ Control Sheaves & Beckets: RWO XT1-43X: | ||
|
Traveller Car with Control Sheaves and Beckets for RWO XT1 Traveller Track
is formed from SS plate with SS axles and a pivoting bail with removable
3/16" Pin for attachment to mainsheet block. Car rides on 5/8" diameter
white Delrin wheels and has (2) 7/8" Sheaves for 1/4" Control lines and integral beckets.
Provides a 3-1 control purchase. Car is (maximum) 4 1/4" long with a maximum width of 1 7/8",
and has an ultimate tensile strength of 500 lbs..
|
||
| 4-wheel Traveller Car w/ Control Blocks & Cams: RWO XT1-44X: | ||
|
As RWO XT1-40 (above), but with the addition of RWO XT1-54
Cam Cleat Adapter Kit. Provides a 2-1 control purchase with Car-mounted Cam Cleats using
line up to 1/4" diameter. Car is (maximum) 4 7/8" long with a maximum width of 1 7/8",
and has an ultimate tensile strength of 500 lbs..
|
||
|
|
Cam Cleat Adapter Kit for RWO XT1-40 Car: RWO XT1-54X: SS Cam Cleat Adapter Kit adds a 2-1 control purchase with Car-mounted Cam Cleats to Standard XT1 Traveller Car. Unit incorporates (2) 1" diameter sheaves, (2) Cam Cleats, and bolts to RWO XT1-40 Car with 3/16" (5mm) screws and locknuts (included). Unit is 4 7/8" long and is suitable for Control lines up to 1/4" diameter. MMM
|
|
| Wheel Replacement Kit for XT1 Traveller Car: RWO XT1-4W: | ||
|
|
Wheel Replacement Kit for RWO XT1 Traveller Cars includes 4 Delrin Wheels.
Machined Delrin Wheels are 5/8" (.650") OD x 3/16" ID x 5/16" wide.
|
|
|
|
||
| RWO XT1 Traveller Ends & Stops | ||
|
XT1 Track End Stop: RWO XT1-20:
Molded Black Plastic Track End covers sharp edges of track and provides a cushion for Traveller Car. Stop measures 1 1/4" long x 1 3/16" wide x 3/4" high, and extends 1 1/8" beyond track. Track End Stop is attached to deck with (1) 3/16" (5mm) FH screw.
|
|
|
|
XT1 Adjustable Track Stop: RWO XT1-21:
Adjustable Track Stop for RWO XT1 Track features 1/4" SS Screw Pin with large knob. Formed SS Adjustable Track Stop is 3/4" long x 15/16" wide. Used on free-floating car systems without end controls, especially for jib and staysail boom travellers. |
 |
|
|
|
||
| XT1 Control Ends & Track Mount Brackets | ||
|
Single Sheave Control End: RWO XT1-25:
Combination End Stop and Single sheave Control End for XT1 Track. Black plastic End incorporates a single 7/8" diameter sheave for use in 1-1, or 2-1 purchase systems where the Control line dead-ends on Traveller Car. Unit is 2 3/8" long x 1 1/8" wide x 1 1/4" high and attaches to deck with (2) 3/16" (5mm) screws on 1" centers.
|
||
|
Side-mount Track Bracket w/ Sheave: RWO XT1-28:
Combination Track Mounting Bracket and Single sheave Control End for XT1 Track. Black plastic Bracket bolts to cockpit side, top of Bracket has vertically mounted 7/8" sheave and holes for Control line dead end, for use in 1-1, or 2-1 purchase systems. Unit is 2 1/8" wide x 2 1/2" high and projects 1 3/8" out from cockpit side. Bracket mounting surface is 2 1/8" wide x 1 5/16" high and attaches to cockpit side with (4) 3/16" (5mm) screws.
|
||
|
|
Replacement Sheave - XT1 Traveller: RWO XT1-42S: Replacement Sheave for XT1-42 Traveller Car and XT1 Control Ends. Black plastic Sheave is 21mm (7/8") OD x 9mm (<3/8") wide x 7mm (<5/16") ID.
|
|
|
Side-mount Track Bracket: RWO XT1-27:
Track Mounting Bracket for XT1 Track. Black plastic Side-mount Bracket bolts to cockpit side with (4) 3/16" (5mm) screws. Unit is 2 1/8" wide x 1 1/4" high and projects 1 3/8" out from cockpit side. |
||
